Cable Ladder Rack CL Series New Sizes Available from Hammond Manufacturing

February 25, 2025

Cable Ladder Rack CL Series New Sizes Available from Hammond Manufacturing

For high-capacity applications in data centres, telecom rooms, and any other densely cabled facilities, the Hammond Cable Ladder (CL Series) is ideal. Although the CL series is intended to mount to Hammond rack mounting products, it may also be mounted on existing racks and cabinets.

Features of Cable Ladder Rack CL Series

  • Manufactured using 16 gauge 1.50in x 0.38in tube steel for the ladder tray.
  • Both horizontal and vertical mounting is possible with the add-on accessories listed below.
  • Mounting hardware is sold separately.
  • Offered in 6″, 12″ and 18″ standard widths. 24″ width available by special order.
  • Rung spaced at 12″. 9″ spacing available by special order.
  • Bonding holes (0.219″ ø) 3″ from end of ladder.
  • Textured RAL9005 black powder paint coat. Complies with the Greenguard guidelines for indoor air quality.
  • Packaged in cardboard with wood at the ends to prevent shipping damage.
  • Load rated to 130 lbs (59 kg) per 1ft (0.3m) when supported every 5ft (1.5m).
  • TAA-compliant for GSA Schedule purchases.
  • RoHS Compliant.
  • Manufactured in North America.
Cable Ladder Rack CL Series New Sizes Available from Hammond Manufacturing

Accessories Cable Ladder Rack CL Series

Source
